THERMALTAKE · VIEW SERIES
Thermaltake VIEW 51 TG ARGB Full-Tower Gaming Cabinet (Black)
A premium full-tower chassis featuring three tempered glass panels, pre-installed ARGB fans, extensive cooling options and spacious component compatibility for high-performance gaming PC builds.
Key Highlights of Thermaltake VIEW 51 TG ARGB
Triple Tempered Glass
Three 4mm tempered glass panels provide a panoramic view of your PC components.
Pre-installed ARGB Fans
Two 200mm front fans and one 120mm rear fan come pre-installed.
E-ATX Motherboard Support
Supports Mini-ITX, Micro-ATX, ATX and E-ATX motherboards up to 10.5 inches wide.
Advanced Cooling Support
Supports multiple fan configurations and radiators up to 360mm at compatible mounting positions.
Introduction to Thermaltake VIEW 51 TG ARGB
The Thermaltake VIEW 51 TG ARGB Full-Tower Gaming Cabinet is designed for enthusiasts who want a spacious chassis with striking aesthetics and extensive hardware compatibility. Its black SPCC steel construction and three 4mm tempered glass panels create a premium showcase for high-performance gaming and custom PC builds.
The cabinet comes equipped with two 200mm 5V ARGB intake fans at the front and one 120mm 5V ARGB exhaust fan at the rear. These pre-installed fans feature addressable lighting, allowing users to customise illumination through the built-in lighting control or compatible motherboard software.
With E-ATX motherboard compatibility, graphics card clearance of up to 440mm without a water pump, support for multiple 360mm radiators and a modular internal layout, the VIEW 51 TG ARGB offers flexibility for advanced PC configurations.
Features and Technologies
Three 4mm Tempered Glass Panels
The three tempered glass panels provide an expansive view of the system interior, making the cabinet ideal for showcasing components, lighting and custom PC configurations.
Pre-installed 5V ARGB Fans
Two 200mm front intake fans and one 120mm rear exhaust fan are included. They feature addressable RGB lighting, hydraulic bearings and multiple lighting modes.
ARGB Lighting Control
The lighting can be controlled through the integrated I/O panel button or compatible motherboard software using a supported 5V addressable RGB header.
Dismantlable Modular Design
Thermaltake's Dismantlable Modular Design allows panels, racks, brackets and mounting arrangements to be removed and configured for easier installation and customisation.
Extensive Cooling Compatibility
The cabinet supports multiple fan sizes and radiator mounting positions, including front, top, right-side and bottom configurations.
High-End Hardware Clearance
With up to 440mm graphics card clearance without a water pump, 175mm CPU cooler clearance and 200mm PSU clearance, the chassis accommodates a wide range of enthusiast components.
Advanced Liquid Cooling and ARGB Customisation
The VIEW 51 TG ARGB supports radiators up to 360mm at the front, top and right-side positions. The bottom also supports a 360mm radiator when the water pump is not installed in the conflicting mounting area. Its pre-installed 5V ARGB fans can be synchronised with compatible motherboard lighting software. Use a supported 5V addressable RGB header and avoid connecting the motherboard lighting control and TT RGB PLUS software simultaneously, as this may cause conflicts.
Technical Specifications
Thermaltake
VIEW 51 TG ARGB
CA-1Q6-00M1WN-00
View Series
Full Tower
Black
SPCC Steel
550 × 315 × 525mm
14.95kg
3 × 4mm Tempered Glass
Mini-ITX, Micro-ATX, ATX, E-ATX (up to 10.5-inch width)
8
2 × 3.5-inch or 2.5-inch (HDD cage)
2 × 2.5-inch (HDD bracket)
Standard PS2 ATX PSU
200mm
175mm
440mm without water pump; 300mm with water pump
2 × 200mm 5V ARGB Fans
1 × 120mm 5V ARGB Fan
2 × 200mm / 3 × 140mm / 3 × 120mm
2 × 200mm / 3 × 140mm / 3 × 120mm
1 × 120mm
2 × 140mm / 3 × 120mm
3 × 120mm
120mm / 140mm / 240mm / 280mm / 360mm
120mm / 140mm / 240mm / 280mm / 360mm
120mm / 140mm / 240mm / 280mm / 360mm
120mm / 240mm / 360mm (without water pump)
1 × USB 3.1 Gen 2 Type-C
2 Ports
2 Ports
1 × HD Audio
Integrated Lighting Control Button
3 Years (as listed by Clarion Computers)
Note: Fan and radiator mounting combinations are subject to available space and component configuration. Maximum GPU clearance is 440mm without a water pump and 300mm with a water pump. Bottom radiator support requires the water pump not to occupy the conflicting mounting area. Warranty is based on the Clarion Computers product listing; confirm applicable terms at purchase.
Ideal Use Cases
High-End Gaming PCs
A spacious chassis for powerful graphics cards, enthusiast motherboards and advanced gaming components.
Custom Liquid-Cooled Builds
Multiple radiator mounting positions make it suitable for custom liquid-cooling configurations.
Showcase PC Builds
Three tempered glass panels and addressable RGB fans create an impressive display for customised PC systems.
Professional Workstations
E-ATX motherboard compatibility and generous internal space make it suitable for powerful workstation configurations.
Before You Buy / Install
- Check motherboard dimensions before purchasing. E-ATX motherboard support is limited to a maximum width of 10.5 inches.
- Verify graphics card clearance. The maximum supported GPU length is 440mm without a water pump and 300mm with a water pump.
- Ensure your CPU cooler height does not exceed 175mm.
- Confirm that your ATX power supply does not exceed the 200mm length limit.
- The bottom radiator position has a water-pump placement restriction. Check the intended pump and radiator layout before installation.
- The cabinet includes two 200mm front ARGB fans and one 120mm rear ARGB fan. Additional fans are sold separately.
- For motherboard ARGB synchronisation, your motherboard must have a compatible 5V addressable RGB header. Do not connect the motherboard lighting control and TT RGB PLUS software simultaneously.
- Check radiator thickness, fan placement and component clearance when planning a custom liquid-cooling loop.
Frequently Asked Questions
Which motherboards are compatible with the Thermaltake VIEW 51 TG ARGB?
The cabinet supports Mini-ITX, Micro-ATX, ATX and E-ATX motherboards. E-ATX motherboard width is supported up to 10.5 inches.
How many fans come pre-installed?
The VIEW 51 TG ARGB comes with three pre-installed 5V ARGB fans: two 200mm fans at the front and one 120mm fan at the rear.
What is the maximum graphics card length supported?
The maximum graphics card length is 440mm without a water pump and 300mm when a water pump is installed.
Does the VIEW 51 TG ARGB support liquid cooling?
Yes. It supports radiators up to 360mm at the front, top and right-side positions. The bottom also supports up to a 360mm radiator when the water pump is not occupying the conflicting mounting area.
How many tempered glass panels does this cabinet have?
The cabinet features three 4mm tempered glass panels, providing an expansive view of the internal PC components.
Can I synchronise the ARGB fans with my motherboard?
Yes. The included 5V ARGB fans support compatible motherboard lighting software. Your motherboard must have a supported 5V addressable RGB header.
What is the maximum CPU cooler height?
The Thermaltake VIEW 51 TG ARGB supports CPU air coolers up to 175mm in height.
How many storage drives can be installed?
The cabinet provides two 2.5-inch drive positions on the HDD bracket and two additional positions that support either 3.5-inch or 2.5-inch drives through the HDD cage.
What connectivity options are available on the front I/O panel?
The front I/O panel includes one USB 3.1 Gen 2 Type-C port, two USB 3.0 ports, two USB 2.0 ports, one HD Audio connection and an RGB control button.
What is the warranty on the Thermaltake VIEW 51 TG ARGB?
The Clarion Computers product listing specifies a 3-year warranty. Please confirm the applicable warranty terms at the time of purchase.
