THERMALTAKE VIEW SERIES
Thermaltake View 600 TG Snow Full Tower Chassis
A premium full tower cabinet featuring four tempered glass panels, extensive cooling support, a spacious interior and compatibility with next-generation hardware.
Key Highlights
Four Tempered Glass Panels
Four 4mm glass panels provide an expansive view of the internal components.
E-ATX Motherboard Support
Supports Mini-ITX, Micro-ATX, ATX and E-ATX motherboard configurations.
420mm Radiator Support
Supports large liquid-cooling radiators at the top and motherboard side.
480mm GPU Clearance
Provides generous graphics card clearance for high-performance PC builds.
Introduction
Build an impressive high-performance PC with the Thermaltake View 600 TG Snow Full Tower Chassis. Designed for enthusiasts and custom PC builders, this full tower cabinet combines a clean Snow White finish with four 4mm tempered glass panels that provide an expansive view of your hardware.
With support for E-ATX motherboards, graphics cards up to 480mm and large 420mm radiators, the View 600 TG offers the space and flexibility required for advanced gaming systems, liquid-cooled builds and professional workstations.
Features and Technologies
Four Tempered Glass Panels
Four 4mm tempered glass panels across the front and left sections create a panoramic showcase for your PC components and lighting.
Hidden-Connector Motherboard Support
Supports selected hidden-connector motherboard designs, including ASUS BTF, MSI PROJECT ZERO and GIGABYTE PROJECT STEALTH models.
Flexible Radiator Compatibility
The top and motherboard-side mounting areas support radiators up to 420mm, allowing flexible liquid-cooling configurations.
Extensive Fan Support
Install up to ten 120mm or 140mm fans across the top, right, rear and power-cover mounting positions.
Rotatable PCIe Slots
Rotatable expansion slots provide flexibility for horizontal or vertical graphics card mounting. A compatible riser cable is sold separately.
Integrated GPU Bracket
The built-in graphics card support bracket helps support heavier graphics cards and improve installation stability.
Flexible Storage Configuration
The drive mounting system supports multiple combinations of 3.5-inch hard drives and 2.5-inch SSDs.
Optional LCD Panel Upgrade
The separately available 6-inch LCD Panel Kit provides an additional customisation option for displaying system information and visual content.
Removable Dust Filters
Top, bottom and motherboard-side dust filters help protect internal components from dust accumulation.
Advanced Cooling and Hardware Flexibility
The View 600 TG Snow supports up to ten 120mm or 140mm fans and provides radiator mounting options up to 420mm at the top and motherboard side. With 480mm graphics card clearance, 175mm CPU cooler clearance and 220mm PSU clearance, it offers generous room for advanced hardware configurations.
Technical Specifications
Thermaltake
View 600 TG Snow
CA-11H-00F6WN-00
Full Tower
Snow White
SPCC Steel
560 × 249 × 584mm
4 × 4mm Tempered Glass
Mini-ITX, Micro-ATX, ATX, E-ATX
Selected Micro-ATX and ATX Models
8
None
10 × 120mm or 140mm
3 × 120mm or 3 × 140mm
3 × 120mm or 3 × 140mm
1 × 120mm or 1 × 140mm
3 × 120mm or 3 × 140mm
120mm, 140mm, 240mm, 280mm, 360mm, 420mm
120mm, 140mm, 240mm, 280mm, 360mm, 420mm
120mm or 140mm
175mm
480mm
220mm
3 × 3.5-inch + 1 × 2.5-inch or 3 × 2.5-inch + 1 × 3.5-inch
1 × USB 3.2 Gen 2
2 × USB 3.0
1 × HD Audio
Standard PS2 PSU (optional)
Note: The cabinet does not include pre-installed fans or a power supply. The optional 6-inch LCD Panel Kit and PCIe riser cable are sold separately. Fan and radiator compatibility depends on the selected installation configuration.
Ideal Use Cases
High-End Gaming PCs
Build powerful gaming systems with support for large graphics cards and advanced cooling components.
Custom Liquid-Cooled Builds
Configure large radiator setups and multiple fans for advanced liquid-cooling systems.
Showcase PC Builds
Display premium components, lighting and custom hardware through four tempered glass panels.
Professional Workstations
Create powerful workstation configurations with E-ATX motherboard and extensive storage support.
Before You Buy / Install
- Check your motherboard dimensions and confirm compatibility with Mini-ITX, Micro-ATX, ATX or E-ATX formats.
- Hidden-connector support applies to selected Micro-ATX and ATX motherboards. Verify the exact motherboard model before purchasing.
- Ensure your graphics card does not exceed the 480mm length clearance.
- Check that your CPU cooler height does not exceed 175mm.
- Confirm that your power supply length is within the 220mm limit.
- The cabinet supports up to ten 120mm or 140mm fans, but fans must be purchased separately.
- Large radiators up to 420mm are supported at the top and right side. Check radiator and component clearance before installation.
- The optional 6-inch LCD Panel Kit and PCIe riser cable are sold separately.
- A standard PS2 power supply is required and is not included with the cabinet.
Frequently Asked Questions
Which motherboards are compatible with Thermaltake View 600 TG Snow?
It supports Mini-ITX, Micro-ATX, ATX and E-ATX motherboards, including selected hidden-connector Micro-ATX and ATX designs.
How many tempered glass panels does the cabinet have?
The View 600 TG Snow features four 4mm tempered glass panels across the front and left sections.
What is the maximum radiator size supported?
The top and right-side mounting areas support radiators up to 420mm. The rear supports 120mm and 140mm radiators.
What is the maximum graphics card length?
The cabinet supports graphics cards up to 480mm in length.
Does the View 600 TG Snow include pre-installed fans?
No. The standard View 600 TG Snow does not include pre-installed fans. Compatible 120mm and 140mm fans can be installed separately.
How many fans can be installed?
It supports up to ten fans across the top, right, rear and power-cover mounting positions, using compatible 120mm or 140mm fans.
Does the cabinet include an LCD screen?
No. The 6-inch LCD Panel Kit is an optional accessory that can be purchased separately.
Is the power supply included?
No. The cabinet supports a standard PS2 power supply, which must be purchased separately.
