| Motherboard |
| Platform |
AMD |
| Socket |
AM5 |
| Cpu Type |
Ryzen 9000,Ryzen 8000,Ryzen 7000 |
| Chipset |
B850 |
| Memory Speed |
up to 8200+ |
| Max Memory Support |
256 GB |
| Supported Memory Type |
DDR5 |
| Channel Supported |
Dual Channel |
| Memory Feature |
Memory Support DDR5 8200 - 5600 (OC) MT/s / 5600 - 4800 (JEDEC) MT/s |
| Ryzen™ 9000 Series Processors max. overclocking frequency: |
| • 1DPC 1R Max speed up to 8200+ MT/s |
| • 1DPC 2R Max speed up to 6400+ MT/s |
| • 2DPC 1R Max speed up to 6400+ MT/s |
| • 2DPC 2R Max speed up to 6000+ MT/s |
| Supports AMD POR Speed and JEDEC Speed |
| Supports Memory Overclocking and AMD EXPOTM |
| Supports Dual-Channel mode |
| Supports Non-ECC, Un-buffered memory |
| Supports CUDIMM, Clock Driver bypass mode only* |
| Graphics Port |
1x HDMI, 1x DisplayPort |
| Expansion Slots |
2x PCI-E x16 slot |
| 1x PCI-E x1 slot |
| PCI_E1 Gen PCIe 4.0 supports up to x16 (From CPU) |
| PCI_E2 Gen PCIe 3.0 supports up to x1 (From Chipset) |
| PCI_E3 Gen PCIe 4.0 supports up to x4 (From Chipset) |
| PCI_E1 slot |
| • Supports PCIe 4.0 x16 (For Ryzen™ 9000/ 7000 Series processors) |
| • Supports PCIe 4.0 x8 (For Ryzen™ 8700/ 8600/ 8400 Series processors) |
| • Supports PCIe 4.0 x4 (For Ryzen™ 8500/ 8300 Series processor) |
| Wireless Networking |
WiFi 6E,Bluetooth 5.3 |
| Back Panel I/O Ports |
Clear CMOS Button |
| DisplayPort 1.4 |
| 2.5G LAN |
| USB 10Gbps (Type-A) |
| Wi-Fi / Bluetooth |
| HD Audio Connectors |
| Flash BIOS Button |
| HDMI |
| USB 10Gbps (Type-A) |
| USB 10Gbps (Type-C) |
| USB 5Gbps (Type-A) |
| Internal I/O Connector |
1x Power Connector(ATX_PWR) |
| 2x Power Connector(CPU_PWR) |
| 1x CPU Fan |
| 1x Combo Fan (Pump_Sys Fan) |
| 4x System Fan |
| 1x EZ Conn-header (JAF_1) |
| 2x Front Panel (JFP) |
| 1x Chassis Intrusion (JCI) |
| 1x Front Audio (JAUD) |
| 1x Com Port (JCOM) |
| 1x Tuning Controller connector(JDASH) |
| 3x Addressable V2 RGB LED connector (JARGB_V2) |
| 1x RGB LED connector(JRGB) |
| 1x TPM pin header(Support TPM 2.0) |
| 4x USB 2.0 ports |
| 2x USB 5Gbps Type A ports |
| 1x USB 10Gbps Type C ports |
| Form Factor |
ATX |
| Warranty |
3 Years |
| Note |
Features, Price and Specifications are subject to change without notice. Images use for Representation Purpose Only. |
