| Specification | |
| Product Number | MLX-D36M-A25SZ-P1 |
| Color | Black |
| CPU Socket Support | Intel: Intel® LGA 1851 / 1700 / 1200 / 1150 / 1151 / 1155 / 1156 |
| AMD: AMD® AM5 / AM4 | |
| Radiator | Material: Aluminum |
| Dimension: 394 x 119.2 x 27 mm | |
| Pump | Dimension: 92.5 x 87 x 39 mm |
| Profiles: Addressable GEN 2 RGB | |
| Speed: 3400 ± 300 RPM | |
| MTTF: > 210,000 hours | |
| Noise Level (Max): 25 dB(A) | |
| Rated Voltage: 12 VDC | |
| Power Consumption: 3.84 W | |
| Connector: 3-Pin ARGB + 4 Pin PWM | |
| Tube | Length: 400 mm |
| Fan | Dimensions: 361 x 122 x 26.5 mm |
| LED Profiles: Addressable GEN 2 RGB | |
| Quantity: 1 PC | |
| Speed: 690 ~ 2500 RPM ± 15% | |
| Air Flow (Max): 322.8 m³/h (190 CFM) | |
| Air Pressure (Max): 3.61 mmH2O | |
| MTTF: > 160,000 hours | |
| Noise Level (Max): 38.5 dB(A) | |
| Bearing: Loop dynamic bearing | |
| Connector: 7-Pin PWM + ARGB | |
| Rated Voltage: 12 VDC | |
| Rated Current: 0.5 A | |
| Safety Current: 0.8 A | |
| Power Consumption: 6 W | |
| Pixel LED | Dimensions: 85.0 x 79.2 x 16 mm |
| Connector: USB Type-C to Motherboard 9pin | |
| Resolution: 28 x 26 px (556 px) | |
| Orientation: Software-MasterCtrl adjustable | |
| Rated Voltage: 5 VDC | |
| Rated Current: 0.5 A | |
| Safety Current: 5.0 A | |
| Power Consumption: 2 W | |
| Warranty | 6 years |
| Note* | Price, feature and specifications are subject to change without notice |
