Printing resolution (dpi)
|
4800* (horizontal) x 1200 (vertical) |
| * Ink droplets can be placed with a pitch of 1/4800 inch at minimum. |
| Interface |
USB Port: |
| Hi-Speed USB *1 |
| LAN Port: |
| Wireless LAN: IEEE802.11n / IEEE802.11g / IEEE802.11b |
| |
| *1 A computer that complies with Hi-Speed USB standard is required. Since the Hi-Speed USB interface is fully upwardly compatible with USB 1.1, it can be used at USB 1.1. |
| USB and LAN can be used at the same time. |
| Print width |
8 inches/203.2 mm |
| (for Borderless Printing: 8.5 inches/216 mm) |
| Printable area |
Borderless printing: Top/Bottom/Left/Right margin: 0.0 inch (0.0 mm) |
| Standard printing: |
| -Top margin: |
| 0.12 inches (3.0 mm) |
| -Bottom margin: |
| 0.20 inches (5.0 mm) |
| -Left margin: |
| Letter/Legal: 0.26 inches (6.4 mm) |
| Other sizes: 0.14 inches (3.4 mm) |
| -Right margin: |
| Letter/Legal: 0.25 inches (6.3 mm) |
| Other sizes: 0.14 inches (3.4 mm) |
| Operating environment |
Temperature: 41 to 95 °F (5 to 35 °C) |
| Humidity: 10 to 90 % RH (no condensation) |
| * The performance of the printer may be reduced under certain temperature and humidity conditions. |
| Recommended conditions: |
| Temperature: 59 to 86 °F (15 to 30 °C) |
| Humidity: 10 to 80 % RH (no condensation) |
| * For the temperature and humidity conditions of papers such as photo paper, refer to the paper's packaging or the supplied instructions. |
| Storage environment |
Temperature: 32 to 104 °F (0 to 40 °C) |
| Humidity: 5 to 95 % RH (no condensation) |
| Power supply |
AC 100-240 V, 50/60 Hz |
| (The supplied power cord is only for the country or region you purchased.) |
| Power consumption |
Printing (Copy): 11 W or less |
| Standby (minimum): 1.2 W or less *1*2 |
| Standby (all ports connected): 1.2 W or less |
| OFF: 0.2 W or less *1 |
| *1 Wireless LAN is active. |
| *2 The wait time for standby cannot be changed. |
| External dimensions |
Approx. 17.6 (W) x 13 (D) x 6.5 (H) inches |
| Approx. 445 (W) x 330 (D) x 163 (H) mm |
| * With the Paper Support and Paper Output Tray retracted. |
| Weight |
Approx. 13.9 lb (Approx. 6.3 kg) |
| * With the Print Head and ink tanks installed. |
| Print Head/Ink |
Total 1472 nozzles (BK 320 nozzles, C/M/Y each 384 nozzles) |
| |
|
| Multiple copy |
max. 20 pages |
| |
|
|
Scan Specifications
|
|
| Scanner driver |
TWAIN 1.9 Specification, WIA |
| Maximum scanning size |
A4/Letter, 8.5" x 11.7"/216 x 297 mm |
| Scanning resolution |
Optical resolution (horizontal x vertical) max: 600 x 1200 dpi |
| * Optical Resolution represents the maximum sampling rate based on ISO 14473. |
| Gradation (Input / Output) |
Gray: 16 bit/8 bit |
| Color: RGB each 16 bit/8 bit |
| |
|
| |
|
|
Network Specifications
|
|
| Communication protocol |
TCP/IP |
| Wireless LAN |
Supported Standards: IEEE802.11n / IEEE802.11g / IEEE802.11b |
| Frequency bandwidth: 2.4 GHz |
| Channel: 1-11 or 1-13 |
| * Frequency bandwidth and available channels differ depending on country or region. |
| Communication distance: Indoors 164 feet/50 m |
| * Effective range varies depending on the installation environment and location. |
| Security: |
| WEP (64/128 bits) |
| WPA-PSK (TKIP/AES) |
| WPA2-PSK (TKIP/AES) |
| Setup: |
| WPS (Push button configuration/PIN code method) |
| WCN (WCN-NET) |
| Easy wireless connect |
| Other Features: Administration password |
| |
|
| |
|
|
Minimum System Requirements
|
|
| Conform to the operating system's requirements when higher than those given here. |
|
| |
|
|
Operating System
|
Windows 10, Windows 8.1, Windows 7 SP1 |
| Note: Operation can only be guaranteed on a PC with pre-installed Windows 7 or later. |
| .NET Framework 4.5.2 or 4.6 is required. |
| Hard Disk Space |
3.1 GB |
| Note: For bundled software installation. |
| The necessary amount of hard disk space may be changed without notice. |
| Display |
XGA 1024 x 768 |
| |
|
| |
|
|
Other Supported OS
|
iOS, Android, Windows 10 Mobile, Chrome OS |
| Some functions may not be available with the supported OS. |
| Refer to the Canon web site for details. |
