| Chipset |
INTEL B860 |
| CPU |
Supports Intel® Core™ Ultra Processors (Series 2) |
| LGA 1851 |
| Memory |
4x DDR5 UDIMM, Maximum Memory Capacity 256GB |
| Memory Support DDR5 8800 - 6400 (OC) MT/s / 6400 - 4800 (JEDEC) MT/s |
| Max. overclocking frequency: |
| • 1DPC 1R Max speed up to 8800+ MT/s |
| • 1DPC 2R Max speed up to 7200+ MT/s |
| • 2DPC 1R Max speed up to 6400+ MT/s |
| • 2DPC 2R Max speed up to 5600+ MT/s |
| |
| Supports Intel® POR Speed and JEDEC Speed |
| Supports Memory Overclocking and Intel® XMP 3.0 |
| Supports Dual-Controller Dual-Channel mode |
| Supports Non-ECC, Un-buffered memory |
| Supports CUDIMM |
| |
| • The DIMM slots on this motherboard only have single-sided latches. |
| • Memory compatibility and supported speeds can vary depending on the CPU and memory configuration. For detailed information, please refer to the Memory Compatibility List available on the product’s Support page or visit https://www.msi.com/support/. |
| Onboard Graphics |
1x HDMI™ |
| Support HDMI™ 2.1 port with TMDS, maximum resolution of 4K 60Hz* |
| 2x DisplayPort |
| Support DisplayPort 1.4 port with HBR2, maximum resolution of 4K 60Hz* |
| 1x VGA |
| Support VGA, maximum resolution of 2048x1536 50Hz, 2048x1280 60Hz, 1920x1200 60Hz |
| *Available only on processors featuring integrated graphics. Graphics specifications may vary depending on the CPU installed. |
| Slot |
2x PCI-E x16 slot |
| PCI_E1 Gen PCIe 5.0 supports up to x16 (From CPU) |
| PCI_E2 Gen PCIe 4.0 supports up to x4 (From Chipset) |
| Audio |
Realtek® ALC897 Codec |
| 7.1-Channel High Definition Audio |
| Storage |
2x M.2 |
| M.2_1 Source (From CPU) supports up to PCIe 5.0 x4 , supports 2280/2260 devices |
| M.2_2 Source (From Chipset) supports up to PCIe 4.0 x4 , supports 2280/2260 devices |
| 4x SATA 6G |
| |
| *Please refer to the manual for M.2 SSD heatsink restrictions. |
| RAID |
Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA storage devices |
| USB |
2x USB 2.0 (Rear) |
| 4x USB 2.0 (Front) |
| 3x USB 5Gbps Type A (Rear) |
| 2x USB 5Gbps Type A (Front) |
| 1x USB 5Gbps Type C (Front) |
| LAN |
Realtek® 8125 2.5Gbps LAN |
| Internal IO |
1x Power Connector(ATX_PWR) |
| 1x Power Connector(CPU_PWR) |
| 1x CPU Fan |
| 1x Combo Fan (Pump_Sys Fan) |
| 2x System Fan |
| 2x Front Panel (JFP) |
| 1x Chassis Intrusion (JCI) |
| 1x Front Audio (JAUD) |
| 1x Printer Port (JLPT) |
| 1x Com Port (JCOM) |
| 3x Addressable V2 RGB LED connector (JARGB_V2) |
| 1x RGB LED connector(JRGB) |
| 1x TPM pin header(Support TPM 2.0) |
| 4x USB 2.0 ports |
| 2x USB 5Gbps Type A ports |
| 1x USB 5Gbps Type C ports |
| WIRELESS LAN & BLUETOOTH |
Wi-Fi 6E |
| The Wireless module is pre-installed in the M.2 (Key-E) slot |
| Supports MU-MIMO TX/RX, 2.4GHz / 5GHz / 6GHz* (160MHz) up to 2.4Gbps |
| Supports 802.11 a/ b/ g/ n/ ac/ ax |
| |
| Supports Bluetooth® 5.3**, FIPS, FISMA |
| |
| * The usage of Wi-Fi 6GHz band relies on Windows 11 support and depends on every country’s regulations. |
| ** The Bluetooth version may be updated, please refer to the Wi-Fi chipset vendor’s website for details. |
| LED FEATURE |
4x EZ Debug LED |
| 1x EZ Memory Detection LED |
