| General |
| Phase |
Single Phase |
| Form Factor |
Tower |
| UPS Topology |
Line-interactive |
| Input |
| Generator Compatibility |
Yes |
| Nominal Input Voltage ( Vac ) |
230 ± 10% |
| Input Voltage Range ( Vac ) |
165 ~ 290 |
| Input Frequency ( Hz ) |
50 ± 10 |
| 60 ± 10 |
| Input Frequency Detection |
Auto-sensing |
| Rated Input Current ( A ) |
10 |
| Input Connector Type |
IN/ZA |
| Power Cord Length (ft.) |
4 |
| Power Cord Length (m.) |
1.2 |
| Output |
| Capacity (VA) |
2200 |
| Capacity (Watts) |
1320 |
| On Battery Waveform |
Simulated Sine Wave |
| On Battery Voltage(s) ( Vac ) |
230 ± 10% |
| On Battery Frequency ( Hz ) |
60 ± 1% |
| 50 ± 1% |
| Automatic Voltage Regulation (AVR) |
Single Boost, Single Buck |
| Overload Protection |
Circuit Breaker |
| Outlet(s) - Total |
4 |
| Outlet Type |
IN/ZA x 4 |
| Outlet(s) - Battery & Surge Protected |
4 |
| Typical Transfer Time ( ms ) |
4 |
| Battery |
| Runtime at 60W ( min ) |
95 |
| Runtime at 90W ( min ) |
70 |
| Typical Recharge Time ( Hours ) |
8 |
| Start On Battery |
Yes |
| User-replaceable |
No |
| Battery Type |
Sealed Lead-acid |
| Replacement Battery Pack (RBP) |
RBP0090 |
| Replacement Battery Pack (RBP) Quantity ( pcs ) |
2 |
| Surge Protection & Filtering |
| Surge Suppression ( Joules ) |
125 |
| EMI/RFI Filtration |
Yes |
| Phone/Network Protection RJ11/RJ45 (Combo) |
1-in, 1-out |
| Management & Communications |
| LED Indicators |
Power On, Line Mode, Battery Mode, Battery Capacity, Low Battery |
| HID Compliant USB Port(s) |
1 |
| Audible Alarms |
Battery Mode, Low Battery, Overload, UPS Fault |
| Management Cable ( pcs ) |
USB Cable x1 |
| Power Management Software |
PowerPanel Personal (Recommended) |
| Physical |
| Enclosure Construction |
Plastic |
| Color |
Black |
| Physical Size - UPS Module |
| Dimensions (WxHxD) (in.) |
5.83 x 7.01 x 11.73 |
| Dimensions (WxHxD) (mm.) |
148 x 178 x 298 |
| Weight (lbs.) |
23.81 |
| Weight (kg.) |
10.8 |
| Shipping Dimensions |
| Dimensions (WxHxD) (in.) |
10.67 x 7.95 x 15.63 |
| Dimensions (WxHxD) (mm.) |
271 x 202 x 397 |
| Weight (lbs.) |
24.47 |
| Weight (kg.) |
11.1 |
| Environmental |
| Operating Temperature (°F) |
32 ~ 104 |
| Operating Temperature (°C) |
0 ~ 40 |
| Operating Relative Humidity (Non-condensing) ( % ) |
0 ~ 90 |
| Operating Elevation ( feet/meters ) |
0-9,843 feet (0-3,000 meters) |
| Storage Temperature (°F) |
-4 ~ 122 |
| Storage Temperature (°C) |
-20 ~ -50 |
| Storage Relative Humidity (Non-condensing) ( % ) |
0 ~ 90 |
| Storage Elevation ( feet/meters ) |
0-9,843 feet (0-3,000 meters) |
| Online Thermal Dissipation ( BTU/hr ) |
170 |
| Audible Noise at 1.5M from Surface of Unit ( dBA ) |
50 |
| Certifications |
| Certifications |
BIS |
| RoHS |
Yes |
| WARRANTY |
| Product Warranty Period (Year) |
2 |
| Battery Warranty Period (Year) |
1 |
| Note |
*** Features, Price, Specifications are subject to change without notice. |
