| Specification |
| Essentials |
Product Collection: Intel® Core™ Ultra Processors (Series 2) |
| Code Name: Products formerly Arrow Lake |
| Vertical Segment: Desktop |
| Processor Number: 270K PLUS |
| Overall Peak TOPS (Int8): 36 |
| CPU Specifications |
Total Cores: 24 |
| # of Performance-cores: 8 |
| # of Efficient-cores: 16 |
| # of Low Power Efficient-cores: 0 |
| Total Threads: 24 |
| Max Turbo Frequency: 5.5 GHz |
| Intel® Turbo Boost Max Technology 3.0 Frequency ‡: 5.5 GHz |
| Performance-core Max Turbo Frequency: 5.4 GHz |
| Efficient-core Max Turbo Frequency: 4.7 GHz |
| Performance-core Base Frequency: 3.7 GHz |
| Efficient-core Base Frequency: 3.2 GHz |
| Cache: 36 MB Intel® Smart Cache |
| Total L2 Cache: 40 MB |
| Processor Base Power: 125 W |
| Maximum Turbo Power: 250 W |
| Intel® Deep Learning Boost (Intel® DL Boost) on CPU: Yes |
| AI Software Frameworks Supported by CPU: OpenVINO™, WindowsML, DirectML, ONNX RT, WebNN |
| CPU Lithography: TSMC N3B |
| Supplemental Information |
Embedded Options Available: No |
| Use Conditions: PC/Client/Tablet, Workstation |
| Memory Specifications |
Max Memory Size (dependent on memory type): 256 GB |
| Memory Types: Up To DDR5 7200 MT/s |
| Max # of Memory Channels: 2 |
| ECC Memory Supported ‡: Yes |
| GPU Specifications |
GPU Name‡: Intel® Graphics |
| Graphics Base Frequency: 300 MHz |
| Graphics Max Dynamic Frequency: 2.0 GHz |
| GPU Peak TOPS (Int8): 8 |
| Graphics Output: eDP1.4b, DP 2.1 UHBR20, HDMI 2.1 FRL |
| Xe-cores: 4 |
| Max Resolution (HDMI)‡: 4096 x 2304 @ 60Hz (HDMI 2.1 TMDS) 7680 x 4320 @ 60Hz (HDMI 2.1 FRL)) |
| Max Resolution (DP)‡: 7680 x 4320 @ 60Hz |
| Max Resolution (eDP - Integrated Flat Panel)‡: 3840 x 2400 @ 120Hz |
| DirectX* Support: 12 |
| OpenGL* Support: 4.5 |
| OpenCL* Support: 3 |
| H.264 Hardware Encode/Decode: Yes |
| H.265 (HEVC) Hardware Encode/Decode: Yes |
| AV1 Encode/Decode: Yes |
| Intel® Quick Sync Video: Yes |
| # of Displays Supported ‡: 4 |
| Device ID: 0x7D67 |
| Intel® Deep Learning Boost (Intel® DL Boost) on GPU: Yes |
| AI Software Frameworks Supported by GPU: OpenVINO™, WindowsML, DirectML, ONNX RT, WebGPU |
| NPU Specifications |
NPU Name‡: Intel® AI Boost |
| NPU Peak TOPS (Int8): 13 |
| Sparsity Support: Yes |
| Windows Studio Effects Support: Yes |
| AI Software Frameworks Supported by NPU: OpenVINO™, WindowsML, DirectML, ONNX RT, WebNN |
| Expansion Options |
Direct Media Interface (DMI) Revision: 4 |
| Max # of DMI Lanes: 8 |
| Intel® Thunderbolt™ 4: Yes |
| Scalability: 1S Only |
| PCI Express Revision: 5.0 and 4.0 |
| PCI Express Configurations ‡: Up to 1x16+2x4, 2x8+2x4, 1x8+4x4 |
| Max # of PCI Express Lanes: 24 |
| Package Specifications |
Sockets Supported: FCLGA1851 |
| Thermal Solution Specification: PCG 2020A |
| Max Operating Temperature: 105 °C |
| Advanced Technologies |
Intel® Gaussian & Neural Accelerator: 3.5 |
| Intel® Thread Director: Yes |
| Intel® Speed Shift Technology: Yes |
| Intel® Turbo Boost Max Technology 3.0 ‡: Yes |
| Intel® Turbo Boost Technology ‡: 2.0 |
| Intel® Hyper-Threading Technology ‡: No |
| Intel® 64 ‡: Yes |
| Instruction Set: 64-bit |
| Instruction Set Extensions: Intel® SSE4.1, Intel® SSE4.2, Intel® AVX2 |
| Idle States: Yes |
| Enhanced Intel SpeedStep® Technology: Yes |
| Thermal Monitoring Technologies: Yes |
| Intel® Volume Management Device (VMD): Yes |
| Security & Reliability |
Intel vPro® Eligibility ‡: Intel vPro® Enterprise |
| Intel® Threat Detection Technology (TDT): Yes |
| Intel® Active Management Technology (AMT) ‡: Yes |
| Intel® Standard Manageability (ISM) ‡: Yes |
| Intel® Remote Platform Erase (RPE) ‡: Yes |
| Intel® One-Click Recovery ‡: Yes |
| Intel® Secure Key: Yes |
| Intel® Control-Flow Enforcement Technology: Yes |
| Intel® Total Memory Encryption - Multi Key: Yes |
| Intel® AES New Instructions: Yes |
| Intel® Trusted Execution Technology ‡: Yes |
| Execute Disable Bit ‡: Yes |
| Intel® OS Guard: Yes |
| Intel® Boot Guard: Yes |
| Mode-based Execute Control (MBEC): Yes |
| Intel® Stable IT Platform Program (SIPP): Yes |
| Intel® Virtualization Technology with Redirect Protection (VT-rp) ‡: Yes |
| Intel® Virtualization Technology (VT-x) ‡: Yes |
| Intel® Virtualization Technology for Directed I/O (VT-d) ‡: Yes |
| Intel® VT-x with Extended Page Tables (EPT) ‡: Yes |
| Warranty |
3 Years |
| Note* |
Price, feature and specifications are subject to change without notice |
