Boosts your existing Wi-Fi coverage to deliver fast and reliable wired and wireless connectivity
External antennas for faster and more reliable Wi-Fi
Supports AP mode which creates a new Wi-Fi Access point
Easily expand wireless coverage at a push of the Range Extender button
Set the Power Schedule for the range extender for power-saving
Works with Any Wi-Fi Router
| Working Modes | Range Extender/Access Point |
| HARDWARE FEATURES | |
| Plug Type | EU, UK, US |
| Interface | 1 x 10/100Mbps Ethernet Port (RJ45) |
| Button | WPS Button, Reset Button |
| Input Power | 100-240V~50/60Hz |
| Max. Power Consumption | 3.6W |
| Dimensions ( W x D x H ) | 3.15 x 3.06 x 3.04 in. (80 x 77.8 x 77.3mm) |
| Antenna | 2 x external |
| WIRELESS FEATURES | |
| Wireless Standards | IEEE 802.11n, IEEE 802.11g, IEEE 802.11b |
| Frequency | 2.4~2.4835GHz |
| Signal Rate | 11n: Up to 300Mbps (dynamic) |
| 11g: Up to 54Mbps (dynamic) | |
| 11b: Up to 11Mbps (dynamic) | |
| Working Modes | Range Extender/Access Point |
| Reception Sensitivity | 270M: <-68dBm@10% PER |
| 130M: <-68dBm@10% PER | |
| 108M: <-68dBm@10% PER | |
| 54M: <-68dBm@10% PER | |
| 11M: <-68dBm@8% PER | |
| 6M: <-68dBm@10% PER | |
| 1M: <-68dBm@8% PER | |
| Wireless Modes | Range Extender/Access Point |
| Wireless Functions | Wireless MAC Address Filtering |
| Domain Login Function | |
| Transmit Power Control | |
| Wireless Security | 64/128/152-bit WEP |
| WPA-PSK / WPA2-PSK | |
| Transmission Power | < 20 dBm (EIRP) |
| OTHER | |
| Network Services Enabled by Default | Web Server |
| Manage and configure device through web (HTTP/HTTPS) | |
| • Port: 80/443 Protocol: TCP | |
| DHCP Server | |
| IP address assignment (DHCP) | |
| • Port: 67 Protocol: UDP | |
| App management | |
| Manage and configure device through app | |
| • Port: 20001 Protocol: TCP | |
| • Port: 20002 Protocol: UDP | |
| OTHERS | |
| Certification | CE, RoHS |
| Package Content | 300Mbps Wi-Fi Range Extender TL-WA855RE |
| Quick Installation Guide | |
| System Requirements | Microsoft® Windows® 98SE, NT, 2000, XP, Vista or Windows 7, 8, 8.1, 10, Mac® OS, NetWare®, UNIX® or Linux. |
| Environment | Operating Temperature: 0°C~40°C (32°F~104°F) |
| Storage Temperature: -40°C~70°C (-40°F~158°F) | |
| Operating Humidity: 10%~90% non-condensing | |
| Storage Humidity: 5%~90% non-condensing | |
