Print Head/Consumables
|
|
| Number of Nozzles |
Total 1,472 nozzles |
| Ink Bottles (Type/Colours) |
GI-790 |
| (Pigment Ink/Black), |
| (Dye-based Ink/Cyan, Magenta, Yellow) |
| Print Heads |
BH-7, CH-7 |
| (Availability may vary by country) |
| Maximum Print Resolution |
4,800 (Horizontal)*1 x 1,200 (Vertical) dpi |
| Document (ESAT/Simplex)*3 |
8.8 / 5 images/minute (Mono/Colour) |
| Document (FPOT Ready/Simplex)*4 |
11 / 17 s (Mono/Colour) |
| Photo (4 x 6") (PP-201/Borderless)*5 |
60 s |
| Print Width |
Bordered: Up to 203.2 mm (8 inch) |
| Borderless: Up to 216 mm (8.5 inch) |
| Recommended Printing Area |
Top margin: 31.2 mm |
| Bottom margin: 32.5 mm |
|
Scan*6
|
|
|
Scanner Type
|
Flatbed (Platen) |
| Scanner Technology |
Contact Image Sensor (CIS) |
| Optical Resolution*7 |
600 x 1,200 dpi |
| Scanning Bit Depth (Input/Output) |
|
| Greyscale |
16 bit / 8 bit |
| Colour |
48 bit / 24 bit (RGB each 16 bit / 8 bit) |
| Maximum Document Size |
|
| Flatbed |
A4, LTR (216 x 297 mm) |
|
Copy
|
|
| Document (Colour): (sFCOT/Simplex) / (sESAT/Simplex) |
32 s / 1.7 images/minute |
| Maximum Copies |
20 pages |
| Maximum Document Size |
A4, LTR |
|
Paper Handling
|
|
|
Print Margin
|
|
| Borderless Printing*9 |
Top/Bottom/Left/Right margin: 0 mm |
| Bordered Printing |
LTR, LGL: |
| Top margin: 3 mm, Bottom margin: 5 mm |
| Left margin: 6.4 mm, Right margin: 6.3 mm |
| |
| Others: |
| Top margin: 3 mm, Bottom margin: 5 mm |
| Left/Right margin: 3.4 mm |
| Supported Media |
|
| Rear Tray |
Plain Paper (64 - 105 g/m²) |
| High Resolution Paper (HR-101N) |
| Photo Paper Plus Glossy II (PP-201, PP-208) |
| Photo Paper Plus Semi-Gloss (SG-201) |
| Matte Photo Paper (MP-101) |
| Envelope |
| Paper Size |
|
| Rear Tray |
A4, A5, B5, LTR, LGL, Envelope (COM10, DL), 10.16 x 15.24 cm (4 x 6 inch), 12.7 x 17.78 cm (5 x 7 inch), 20.32 x 25.40 cm (8 x 10 inch), Square (127 x 127 mm), Business Card |
| |
| [Custom Size] |
| Width: 55 - 215.9 mm |
| Length: 89 - 676 mm |
| |
| *F4 is possible via custom size settings. |
| Borderless Printing*9 |
A4, Letter, 10.16 x 15.24 cm (4 x 6 inch), 12.7 x 17.78 cm (5 x 7 inch), 20.32 x 25.40 cm (8 x 10 inch), Square (127 x 127 mm), Business Card |
| Maximum Capacity |
|
| Rear Tray |
Plain Paper (A4, A5, B5, LTR, 64 g/m²): 100 |
| High Resolution Paper (HR,101N): 80 |
| Photo Paper Plus Glossy II (PP-201, PP-208, 10.16 x 15.24 cm (4 x 6 inch)): 20 |
| Photo Paper Plus Semi-Gloss (SG-201, 10.16 x 15.24 cm (4 x 6 inch)): 10 |
| Matte Photo Paper (MP-101, 10.16 x 15.24 cm (4 x 6 inch)): 20 |
| Envelope (COM10, DL): 10 |
| Paper Weight |
|
| Rear Tray |
Plain Paper: 64 - 105 g/m² |
| Canon Paper: Approx. 275 g/m² (Max.) |
| (Photo Paper Plus Glossy II, PP-201) |
|
System Requirements
|
|
|
OS System Compatibility*10
|
Windows 10 / 8.1 / 7 SP1, |
| macOS is not supported |
|
General Specifications
|
|
|
Operation Panel
|
|
| Display |
3.04 cm (1.2 inch) LCD Segment Mono |
| Interface |
USB 2.0 |
| Operating Environment*11 |
|
| Temperature |
5 - 35°C |
| Humidity |
10 - 90% RH (no dew condensation) |
| Recommended Environment*12 |
|
| Temperature |
15 - 30°C |
| Humidity |
10 - 80% RH (no dew condensation) |
| Storage Environment |
|
| Temperature |
0 - 40°C |
| Humidity |
5 - 95% RH (no dew condensation) |
| Quiet Mode |
Available |
| Acoustic Noise*13 |
|
| Plain Paper (A4, Mono) |
53.5 dB(A) |
| Power Requirements |
AC 100 - 240 V, 50/60 Hz |
| Power Consumption (Approx.) |
|
| OFF |
0.2 W |
| Standby |
0.6 W |
| Operation*14 |
9 W |
| Dimensions (W x D x H) |
|
| Factory Configuration |
445 x 330 x 163 mm |
| Output Trays Extended |
445 x 533 x 260 mm |
| Weight |
6.3 kg |
|
Page Yield*15
|
|
|
Plain Paper
|
A4 Colour Documents*16: |
