Intel RNUC13RNGI90000 NUC 13 Extreme Raptor Canyon with Intel Core i9-13900K processor


Out of stock

164,299 199,999

Out of stock

176,637 for 3 item(s)

Intel RNUC13RNGI90000 NUC 13 Extreme Raptor Canyon With Intel Core i9-13900K Processor

Intel Mini PC


SKU: RNUC13RNGi90000 Category: Tags: ,
ARK | Compare Intel® Products
Intel® NUC 13 Extreme Kit – RNUC13RNGi90000
Product Collection Intel® NUC Kit with 13th Generation Intel® Core™ Processors
Code Name Products formerly Raptor Canyon
Processor Included Intel® Core™ i9-13900K Processor (36M Cache |  up to 5.80 GHz)
Discrete Graphics Supports PCIe x16 Gen5 3-slot wide GPU
Board Number NUC13SBBi9
Board Chipset Intel® Z690 Chipset
Supported Operating Systems Windows 11 |  64-bit*
Supplemental Information
Marketing Status Launched
Launch Date Q4’22
Warranty Period 3  yrs
Embedded Options Available No
CPU Specifications
Total Cores 24
Total Threads 32
Max Turbo Frequency 5.80 GHz
Memory & Storage
Max Memory Size (dependent on memory type) 64 GB
# of Memory Slots 2
Memory Types DDR5 SODIMM
Max # of Memory Channels 2
ECC Memory Supported   ‡ No
# of Internal Drives Supported 5
M.2 Card Slot (storage) 2x via PCH + 1x via CPU (NVMe)
I/O Specifications
Graphics Output 2x Thunderbolt 4 |  HDMI 2.1 TMDS compatible (4K60)
# of Displays Supported ‡ 3
# of Thunderbolt™ Ports 2x Thunderbolt™ 4
# of USB Ports 11
USB Configuration Rear: 6x USB 3.2g2 |  2x TB4 (USB4); Front: 2x USB 3.2g1 Type-A |  USB 3.2g2x2 Type-C
USB Revision 3.2 Gen1 |  Gen2 |  Gen2x2 |  USB4
Total # of SATA Ports 4
Max # of SATA 6.0 Gb/s Ports 4
RAID Configuration RAID-0 or RAID-1
Audio (back channel + front channel) (R) 7.1 digital |  3x 3.5mm + (F) 3.5mm
Integrated LAN 10GbE (AQC113) + Intel® i226-V
Wireless Included Intel® Killer™ Wi-Fi 6E AX1690 (i/s)
Bluetooth Version 5.3
M.2 Card Slot (wireless) Killer™ Wi-Fi 6E AX1690i
Additional Headers FRONT_PANEL
Expansion Options
PCI Express Revision Gen5 |  Gen4
Package Specifications
TDP 125 W
Chassis Dimensions 337 x 318 x 129mm
Board Form Factor PCIe
Advanced Technologies
Intel® Rapid Storage Technology Yes
Intel® Optane™ Memory Supported ‡ Yes
Intel® Virtualization Technology for Directed I/O (VT-d) ‡ Yes
Intel® Virtualization Technology (VT-x) ‡ Yes
Security & Reliability
Intel® Platform Trust Technology (Intel® PTT) Yes
Intel® AES New Instructions Yes
